Duză de gaz (gas nozzle) a x b x c x d mm
No. 4 7990766 18.0 x 11.5 x 6.5 x 47.5
No. 5 7990770 18.0 x 12.5 x 8.0 x 47.5
No. 6 7990771 18.0 x 14.5 x 9.5 x 47.5
No. 7 7990772 18.0 x 16.0 x 11.0 x 47.5
No. 8 7990773 18.0 x 18.0 x 12.5 x 47.5
No.10 7990775 21.0 x 21.0 x 16.0 x 47.5
No.12 7990776 24.0 x 24.0 x 19.0 x 47.5 |
 |
Duză de gaz cu lentilă (gas nozzle lens) a x b x c x d mm
No. 5 7990783 25.0 x 12.5 x 7.5 x 42.0
No. 6 7990784 25.0 x 14.0 x 9.0 x 42.0
No. 7 7990785 25.0 x 15.5 x 11.0 x 42.0
No. 8 7990786 25.0 x 16.5 x 12.0 x 42.0
No.11 7990787 25.0 x 22.0 x 17.0 x 42.0 |
| |
|
 |
Portpensetă / carcasă strângere (housing for tightening bush) |
Standard
Ø 1.6 - 2.4 - 3.2 - 4.0 |
Lentilă de gaz (gas lens)
Ø 1.6 - 2.4 - 3.2 - 4.0 |
| |
|
 |
Inel de izolare (insulating ring)
9580266 - 9876860 - 9580267 |
| |
|
 |
Corp pistolet (torch body)
• lista completă Corpuri pistolete wig-tig Kemppi |
 |
Pensetă (tightening bush)
Ø 1.6 9876867
Ø 2.4 9876868
Ø 3.2 9876869
Ø 4.0 9876870 |
| |
|
 |
Capac pistolet (scut electrod), inel garnitură inclus (electrode shield)
7990731 scurt (short)
7990735 mediu
7990741 lung (long) |
 |
Inel garnitură (o-ring)
7990791 |
| |
|
Electrod gri (grey)
Ø 1.6 - 2.4 - 3.2 - 4.0 |
Electrod alb (white)
Ø 1.6 - 2.4 - 3.2 - 4.0 |
Electrod verde (green)
Ø 4.0 |
